A polyurethane hose with outstanding elasticity providing excellent flexibility and kink-resistance, even in extreme cold conditions.
A polyurethane hose with outstanding elasticity providing excellent flexibility and kink-resistance, even in extreme cold conditions.
| Product Ref | Internal Diameter | External Diameter | Maximum Working Pressure | Minimum Burst Pressure | Weight per Meter | Bend Radius |
|---|---|---|---|---|---|---|
| CR03 | 3.2mm | 8mm | 32 Bar | 128 Bar | 0.056 Kg | 20mm |
| CR05 | 5mm | 10mm | 27 Bar | 108 Bar | 0.074 Kg | 20mm |
| CR06 | 6.3mm | 11.5mm | 16 Bar | 64 Bar | 0.093 Kg | 28mm |
| CR08 | 8mm | 13.5mm | 16 Bar | 64 Bar | 0.123 Kg | 29mm |
| CR10 | 10mm | 16mm | 15 Bar | 60 Bar | 0.163 Kg | 40mm |
| CR12 | 12.5mm | 18.5mm | 15 Bar | 60 Bar | 0.187 Kg | 55mm |
| CR16 | 16mm | 23mm | 12 Bar | 48 Bar | 0.269 Kg | 95mm |
| CR19 | 19mm | 26mm | 10 Bar | 40 Bar | 0.310 Kg | 135mm |
| CR22 | 22mm | 29mm | 10 Bar | 40 Bar | 0.347 Kg | 104mm |
| CR25 | 25mm | 32mm | 10 Bar | 40 Bar | 0.432 Kg | 210mm |
| CR32 | 32mm | 42mm | 10 Bar | 40 Bar | 0.684 Kg | 320mm |
| CR38 | 38mm | 48mm | 10 Bar | 40 Bar | 0.684 Kg | 420mm |
| CR50 | 50mm | 62mm | 8 Bar | 32 Bar | 1.476 Kg | 650mm |
| CPR06 | 6.3mm | 12mm | 13 Bar | 40 Bar | 0.113 Kg | 70mm |
| CPR08 | 8mm | 14mm | 11 Bar | 33 Bar | 0.140 Kg | 82mm |
| CPR10 | 10mm | 15.75mm | 10 Bar | 30 Bar | 0.143 Kg | 95mm |
| CPR12 | 12.5mm | 18.5mm | 7 Bar | 21 Bar | 0.183 Kg | 110mm |
| CPR16 | 16mm | 23mm | 7 Bar | 21 Bar | 0.285 Kg | 140mm |
| CPR19 | 19mm | 26mm | 6 Bar | 18 Bar | 0.358 Kg | 155mm |
| CPR25 | 25mm | 34mm | 3.5 Bar | 10.5 Bar | 0.500 Kg | 200mm |
