Compact Preformed Airline Coils

EC Series

RoHS 3 Compliant
Phthalate Free
Working Temperature
Made in Britain Made in Britain

An off-the-shelf solution satisfying all market sectors requiring a lightweight Type 12 Nylon airline coil with high resistance to oil, organic and non-organic media.

Key Features

  • Excellent flexibility / retention.
  • Light weight.
  • Superior flow characteristics.
  • BSPT Male Swivel fittings (compression) complete with anti-kink spring.
  • Suitable for horizontal and vertical applications.
  • Temperature range -40oC to +80oC.
  • Maximum Working Pressure = 15 bar.
  • RoHS 3 compliant.

Sizes

  • 8mm, 10mm & 12mm OD in working lengths of 2.5m, 5m, 10m and 15m
  • Fittings 1⁄4 BSPT and 3/8 BSPT

Colours

  • Red
  • Blue
  • Other colours are available on request

Materials

  1. BSP Male Swivel With Spring Guards
  2. Impact modified PA12
Air Tools

Applications

  • Industrial air tools
  • Production line assembly

Datasheet

This product information is also available in PDF format.

Download Datasheet
Product ReferencesTube SizeWorking Length (m)Number of TurnsTail LengthsCoil DiameterFittings
EC088 x 6mm2.5 . 5 . 10 . 1513 . 27 . 55 . 86500 / 100mm76mm1/4" BSP Male Swivel With Spring Guards
EC1010 x 8mm2.5 . 5 . 10 . -13 . 26 . 53 . -500 / 100mm76mm1/4" BSP Male Swivel With Spring Guards
EC1212 x 9mm2.5 . 5 . 10 . -11 . 23 . 46 . -500 / 1000m90mm3/8" BSP Male Swivel With Spring Guards

Product Data

Select two or more columns from the table above to compare the data in this table.
